AvanceTM III HD NanoBay 400 MHz NMR Spectrometer
Department of Chemistry, COMSATS University Islamabad, Abbottabad
About NMR
AvanceTM III HD NanoBay 400 MHz NMR Spectrometer.
The Nuclear Magnetic Resonance (NMR) spectrometer at the Department of Chemistry is a fully equipped modern facility. The new AvanceTM III HD NanoBay NMR device is a highly integrated state-of-the-art broadband NMR spectrometer ever. The novel NanoBay design places Bruker’s high-performance HD NMR spectrometer technology into anexceptionally compact enclosure.
The NanoBay delivers high productivity and highest-quality NMR information for pharmaceutical and industrial chemists, for academic research and teaching, as well as for food analysis, diagnostics research and other small molecule applications
Features
- Broadband compact design high end NMR spectrometer.
- Easy siting in small analytical laboratories.
- Based on latest AvanceTM III HD spectrometer technology.
- Includes most stable and compact AvanceTM magnet technology.
- Intuitive routine user interface TopSpinTM.
- Single probe for direct and indirect detection experiments.
- Increases efficiency and throughput in automation.
- Broadband channel tunable from 15N to 19F under full automation with Bruker ATMTM.
- 19F applications including 1H decoupling and vice versa.
The SmartProbeTM delivers highest sensitivity on both the multinuclear and prolon channel, Its design exclusively features a broadband frequency channel enabling fully automated applications on protons and the widest range of X-nuclei.
For maximum flexibility switching nuclei and probe tuning and matching is performed completely automatically using our ATMTM technology. A further key feature which the probe offers is the ability to observe 19F with 1H decoupling and to perform two-dimensional 1H/19F spectroscopy with superior quality. As two separate coils are used for these two nuclei, artefacts common with double tuning of one coil are eliminated.
The high-performance Z-gradient has been designed for highest linearity and shortest gradient recovery times. Combined with its excellent line shape, this probe facilitates superior single or multiple solvent suppression using pre-saturation or pulsed field gradients as required for samples from reaction control, biological samples, and body fluids. The SmartProbeTM is the ideal probe for a wide range of applications from routine 1H NMR measurements on small molecules to advanced research applications including inverse experiments requiring excellent solvent suppression
